9 Functions in 1 device. Built in OPM OLS VFL Event Map RJ45 Ethernet Cable Sequence Distance Tracker. One-click automatic test, automatic file saving, automatic analysis of test results.
100km Range
Multi-touch capacitive screen
Support New gesture magnification function and screen capture
Item NO.:
S760Order(MOQ):
1Payment:
T/T, Paypal, Western Union, Moneygram, etc.Product Origin:
ChinaColor:
StandardShipping Port:
Nanjing/Shanghai/Guangzhou/Shenzhen/etc.
This series of OTDR is a multi-functional optical measuring instrument, which integrates auto OTDR, expert OTDR, event map, optical power meter, visual fault location, power adjustable stable light source, end face detection, optical loss test, cable line length / sequence test, cable tracking and other functions. It has touch screen and heys. It is the right assistant for optical cable construction, installation and maintenance, project acceptance and on-site repair.
Product Overview
OTDR- S760 Mini Pro series OTDR adopts 4.3-inch ca pacitivetouch screen. It integrates 12 functions, such as auto OTDR,expert OTDR, event map, OPM, RJ45 cable tracker, and "com-puter level" file management to meet various test require-ments in different occasions. OTDR has a maximum dynamicrange of 26dB, 8G memory, and can store more than 200,000curves; it is equipped with 4000mAh high-density polymerlithium battery, intelligent power saving management, mea-suring time of more than 8 hours, and supporting powersupply and charging of the power bank.
OTDR-S760 series are used to measure the length, loss,connection quality and other parameters of optical fiber. It iswidely used in FTTX, secondary backbone network engineer-ing construction, maintenance and emergency repair test,and production measurement of optical fiber and cable.
9 Functions in 1 device. Built in OPM OLS VFL Event Map RJ45 Ethernet Cable Sequence Distance Tracker. One-click automatic test, automatic file saving, automatic analysis of test results.
Latest 9-in-1 functions mini OTDR Tester. Cost-effective optical network analysis test equipment, with the features of lightweight, easily useable.
3.5 inch color LCD portable design and easy to carry.
Portable, rugged, lightweight, Easy to use. More accurate testing results and better repeatability. Automatic Pulse Width Control design to ensure a convenient operation.
Pro mini OTDR Fiber Optic Reflectometer with Functions VFL OLS OPM. It is widely used in FTTX, secondary backbone network engineering construction, aintenance and emergency repair test, and production measurement of optical fiber and cable
compact and easy to carry 1550nm wavelength active fiber live test
Smart Series Optical Time Domain Reflectometer adopts a 3.5-inch color capacitive touch screen, Which is simple to operate. It integrates eight major functions such as OTDR, Event map, Stable light source, optical power meter, red light source, Network Line Sequence Test, line finding and lighting. Simple parameter setting and intelligent measurement make the operation more simple and efficient. The model is small and light, easy to carry. The wireless charging function is supported, and the large capacity battery ensures 10 hours of ultra long time measurement and 20 hours of ultra long standby, providing guarantee for field testing.
Rugged and easy-to-use. It can quickly identify the direction of transmitted fiber and detect the presence of signals on optical fibers.
IPv6 network supported
